ECturn * Electromechanical swing door drive for accessible single leaf doors weighing up to 125 kg
- Opening and closing speed can be individually adjusted
- Electrical latching action which accelerates the door shortly before the closed position
- Low-energy function opens and closes the door with reduced speed, fulfilling the highest safety demands
- Obstacle detection detects an object through contact and stops the opening or closing process
- Automatic reversing detects an obstacle and returns to the opening position
- Push & Go function triggers the automatic drive following light manual pressure on the door leaf
- Drive can be used with guide rail or link arm
- Glass guide rail available for use on glass doors with a glass thickness of 8-10 mm
- Optional rechargeable battery provides maximum safety during a power failure
- Optional radio reception board for wireless activation by radio transmitter
Application Areas
- Single-action, single leaf, right and left closing doors
- Single-action doors up to 1100 mm leaf width or 125 kg weight
- Entrance and interior doors with moderate access frequency
- Automation of frameless all-glass doors
- Door leaf installation and transom installation
- Barrier-free access
Installation situations in reference objects and videos
Technical data
ECturn | |
Height | 60 mm |
Depth | 60 mm |
Leaf weight (max.) 1-leaf | 125 kg |
Leaf width (min.-max.) | 650 mm - 1100 mm |
Reveal depth (max.) | 200 mm |
Door overlap (max.) | 50 mm |
Drive type | Electromechanical |
Opening angle (max.) | 110 ° |
DIN left | Yes |
DIN right | Yes |
Transom installation opposite hinge side with link arm | Yes |
Transom installation opposite hinge side with guide rail | Yes |
Transom installation hinge side with guide rail | Yes |
Transom installation opposite hinge side with guide rail on all-glass doors | Yes |
Transom installation hinge side with guide rail on all-glass doors | Yes |
Door leaf installation opposite hinge side with guide rail | Yes |
Door leaf installation hinge side with guide rail | Yes |
Door leaf installation hinge side with link arm | Yes |
Electrical latching action | Yes |
Disconnection from mains | Main switch in the drive |
Activation delay (max.) | 10 s |
Operating voltage | 110 – 230 V |
Power rating | 75 W |
Power supply for external consumers (24 V DC) | 600 mA |
Service temperature | -15 - 50 °C |
IP rating | IP20 |
Mode of operation | Off, Automatic, Permanently open, Night |
Type of function | Fully automatic |
Automatic function | Yes |
Low-energy function | Yes |
Key function | Yes |
Obstacle detection | Yes |
Automatic reversing | Yes |
Push & Go | adjustable |
Operation | Programme switch TPS, Programme switch integrated in the drive |
Parameter setting | Programme switch DPS, Control unit |
Standard conformity | EN 16005 |
Downloads
LABELLING OBLIGATION: © Studio BE / GEZE GmbH
LABELLING OBLIGATION: © Studio BE / GEZE GmbH
LABELLING OBLIGATION: © Studio BE / GEZE GmbH
LABELLING OBLIGATION: © Studio BE / GEZE GmbH
LABELLING OBLIGATION: © GEZE GmbH
LABELLING OBLIGATION: © GEZE GmbH
LABELLING OBLIGATION: © GEZE GmbH
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
