ECdrive
ECdrive T2 eco * Automatic sliding door system for doors with a leaf weight of up to 100 kg
- Simplified commissioning and parameter setting thanks to reduced functional properties
- Eco mode permanently active to reduce the power consumption of activation and safety sensors in hold open, night mode, and off modes of operation
- Efficient installation thanks to pre-drilled tracks and elongated holes
- Profile lengths of the track and cover optimised for the application, measuring 2600 mm and 4500 mm respectively
- Integrated cable routings make cable laying easier
- Independent error recognition and recording
- Configurable output for error transmission
- Integrated rechargeable battery for continued operation during power failures for a maximum of 30 minutes or 30 cycles
- Self-cleaning roller carriage reduces maintenance effort and costs
- Electric toothed belt locking available as an option
The ECdrive T2 eco offers a sleek design for a wide range of configuration options and is particularly easy to commission thanks to its reduced functions. Eco mode minimises the energy consumption of activation and safety sensors and ensures efficient and sustainable operation.
Application Areas
- Single and double leaf sliding door systems
- Interior and exterior doors with moderate usage
- Suitable profile systems are fine-framed profile systems with ISO and mono glass, on-site frame and wooden leaves
Installation situations in reference objects and videos
Sliding door solutions from GEZE, product video
ECdrive T2, Slimdrive and Powerdrive: Tailored, efficient and open to the demands of tomorrow.
Technical data
| ECdrive T2 eco | |
| For 1-leaf door systems | Yes |
| For 2-leaf door systems | Yes |
| Fine-framed insulating glass | Yes |
| MONO glass fine-framed | Yes |
| ESG clamping profile | Yes |
| Framed leaf (on site) | Yes |
| Wooden leaf (on site) | Yes |
| Height | 100 mm |
| Depth | 190 mm |
| Leaf weight (max.) 1-leaf | 100 kg |
| Leaf weight (max.) 2-leaf | 100 kg |
| Opening width 1-leaf | 700 mm - 1200 mm |
| Opening width 2-leaf | 900 mm - 2200 mm |
| Service temperature | -15 - 50 °C |
| IP rating | IP20 |
| Disconnection from mains | Main switch in the drive |
| Standard conformity | DIN EN 16005. DIN EN ISO 13849: Performance Level D |
Downloads
ECdrive T2 / ECdrive T2-FR
LABELLING OBLIGATION:
© GEZE GmbH
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
